OroCommerce Form : create color picker field




video




The Complete Course


Orocommerce is new  b2b ecommerce system , this system will need customizable themes , and the frontend developer need know how use color picker field for giving the ability to user for customizing the theme from admin panel ,



Ok orocommerce is built on top of oro platform , and the platform propose to you a lot of form type , you can find all in path vendor/oro/platform/src/Oro/Bundle/FormBundle/Form/Type/ .
One of them is OroSimpleColorPickerType and OroSimpleColorChoiceType . Let's try using simple example of how you can use  OroSimpleColorPickerType .

In your Entity for example create property  backgroundColor :

  1.
  2.     /**
  3.      * @var string|null
  4.      *
  5.      * @ORM\Column(name="background_color", type="string", length=7, nullable=true)
  6.      */
  7.     protected $backgroundColor;
  8.


and inside you form type you can add field related to this property :

  1.
  2.             ->add(
  3.                 'backgroundColor',
  4.                 'oro_simple_color_picker',
  5.                 [
  6.                     'required'           => false,
  7.                     'label'              => 'oro.calendar.calendarevent.background_color.label',
  8.                     'color_schema'       => 'oro_calendar.event_colors',
  9.                     'empty_value'        => 'oro.calendar.calendarevent.no_color',
  10.                     'allow_empty_color'  => true,
  11.                     'allow_custom_color' => true
  12.                 ]
  13.             )
  14.

you have here lot of options :
allow_empty_color : transparent or without color , the system will add square of no color
allow_custom_color : the user can choose any color from color picker
empty_value : label of no color choice example in calendar 'Use calendar color'
color_schema : just go to path vendor/oro/calendar-bundle/Oro/Bundle/CalendarBundle/DependencyInjection/Configuration.php
you will find a global variable passed by di content the custom color of default square proposed by the oro_simple_color_picker
example :

  1.
  2.                 'event_colors'    => [
  3.                     'value' => [
  4.                         '#5484ED',
  5.                         '#A4BDFC',
  6.                         '#46D6DB',
  7.                         '#7AE7BF',
  8.                         '#51B749',
  9.                         '#FBD75B',
  10.                         '#FFB878',
  11.                         '#FF887C',
  12.                         '#DC2127',
  13.                         '#DBADFF',
  14.                         '#E1E1E1'
  15.                     ]
  16.

you can use  OroSimpleColorChoiceType with alias oro_simple_color_choice the big different with  OroSimpleColorPickerType   , the oro_simple_color_choice don't allow custom choice of color :
example :

  1.
  2.         $builder->add(
  3.             'border',
  4.             'oro_simple_color_choice',
  5.             array(
  6.                 'label'    => 'ibnab.pmanager.producttemplate.border.label',
  7.                 'required' => false,
  8.             )
  9.         );
  10.
  11.

Other Thing you can use this field in system configuration example with  oro_color_table (more colmplex field):

  1.
  2. system_configuration:
  3.     groups:
  4.         calendar_settings:
  5.             title:       oro.calendar.system_configuration.groups.calendar_settings.title
  6.     fields:
  7.         oro_calendar.calendar_colors:
  8.             data_type: array
  9.             type: oro_color_table
  10.             options:
  11.                 label: oro.calendar.system_configuration.fields.calendar_colors.label
  12.         oro_calendar.event_colors:
  13.             data_type: array
  14.             type: oro_color_table
  15.             options:
  16.                 label: oro.calendar.system_configuration.fields.event_colors.label
  17.     tree:
  18.         system_configuration:
  19.             platform:
  20.                 children:
  21.                     general_setup:
  22.                         children:
  23.                             look_and_feel:
  24.                                 children:
  25.                                     calendar_settings:
  26.                                         children:
  27.                                             - oro_calendar.calendar_colors
  28.                                             - oro_calendar.event_colors
  29.

you can now use the picker or choicer ot color table …..
